American Forge & Foundry Ram - Hydraulic - 10 Ton Capacity - Compressed Length: 12.68" - Extended Length: 17.8" - 5.25" Stroke - Coupler: 1/4" 18NPTF

Features and Benefits:

• Color: Red/Black
• Product Type: Hydraulic Ram
• Ram Capacity (Tons): 10
• Stroke (Inch): 5.25”
• Effective Area (Square Inch): 2.46
• Oil Capacity (ml): 207
• Collapsed Height (Closed) Inch: 12.68
• Ram Extended Height (Inch): 17.8
• Outside Diameter of the Unit (Inch): 2.16
• Diameter of the Ram (Inch): 1.57
• Saddle Diameter (Inch): 1.3
• Optimal Pressure: 8,937 PSI
• Weight (Lbs.): 9.81
• Warranty: 1 Year
• 10 Ton ‐ 5.25" Stroke - 1/4" 18 NPTF female coupler.
• Designed for use in all positions with high strength allow steel for durability.
• Heavy duty return spring allows smooth return function.
• Baked enamel finish for increased corrosion resistance.
• Collar thread protector.
• Rod wipers seal out contaminants.
• Chrome plated ram prevents rust and corrosion.



Offering a wide assortment of Hydraulic Rams for use in high force applications including lifting, pulling, pushing, bending and alignment. Choose from complete kits or individual styles.
